PVC electronic cables
MTW, THHW, THW, TW Wire

Application
The single core MTW, THHW, THW ,TW is suitable for appliance wiring and machine tool wiring as well as in control systems. They can also be used in pipes and flexible conduits.
Characteristics
- 규격(Standard) : UL, CSA 공용(UL,CSA for both use)
- 난연성이 우수하며 Oil 저항에 강하고 외부 노출에도 강하여 전원공급용 배선으로 적합함.
- 완성 외경이 가늘어 배선 면적을 줄일 수 있음.
- 유연성이 탁월하여 좁은 공간에서 심한 굴곡을 원하는 배선 작업에 용의함.
- UL Subject 758 or 83 or 1063 or 1581
Specifications
CATALOG NUMBER Size Conductor Insulation Current
Max.(A)		 Resistance
(Ω/km)		 Capacitance
[pF/m]		 About
weight
100m/Kg
AWG SO Construction
(No./mm)		 Dia
(mm)		 Thick
(mm)		 Overall
Dia.(mm)
WG0801C-080025 20 0.5 26/0.16 0.94 0.8 2.5 11.9 35.60 110 1.23
WG1801C-080028 18 0.8 41/0.16 1.18 0.8 2.8 15.6 22.58 120 1.63
WG1601C-080031 16 1.25 26/0.254 1.49 0.8 3.1 20.9 14.13 130 2.24
WG1401C-090037 14 2.0 41/0.254 1.88 0.9 3.7 28.2 8.96 140 3.34
WG1201C-100044 12 3.5 65/0.254 2.36 1.0 4.4 38.3 5.65 140 4.98
WG1001C-100050 10 5.5 105/0.254 3.00 1.0 5.0 52 3.50 160 7.31
WG0801C-120067 8 8 7/24/0.254 4.31 1.2 6.7 72.1 2.19 160 11.92
WG0601C-160086 6 14 7/38/0.254 5.42 1.6 8.6 98.1 1.38 160 19.29
WG0401C-180104 4 22 7/60/0.254 6.81 1.8 10.4 129.9 0.87 170 29.31
WG0201C-200127 2 30 19/35/0.254 8.67 2.0 12.7 176.2 0.55 180 44.82
WG0101C-220141 1 40 19/44/0.254 9.72 2.2 14.1 198.1 0.44 180 55.99
WG1/001C-220153 1/0 50 19/55/0.254 10.87 2.2 15.3 229 0.35 180 68.01
WG2/001C-240171 2/0 70 19/70/0.254 12.26 2.4 17.1 255.9 0.28 180 85.65
WG3/001C-240186 3/0 80 19/88/0.254 13.75 2.4 18.6 297 0.22 190 104.9
WG4/001C-260207 4/0 100 37/57/0.254 15.49 2.6 20.7 329.2 0.17 190 131.69
WG25001C-260222 250 125 37/43/0.320 16.95 2.6 22.2 370 0.15 200 154.86
WG30001C-280242 300 150 37/52/0.320 18.64 2.8 24.2 417.8 0.12 200 186.5
WG35001C-300260 350 180 37/60/0.320 20.02 3.0 26.0 457.4 0.10 200 215.13
WG40001C-300273 400 200 37/68/0.320 21.32 3.0 27.3 465.3 0.09 200 240.54
WG45001C-340296 450 225 37/78/0.320 22.83 3.4 29.6 505.8 0.08 200 278.77
WG50001C-340308 500 250 37/88/0.320 23.97 3.4 30.8 538.5 0.07 200 304.71
